Ohms
Versions
American Bass
XD 10″ Car Subwoofer | 450 Watts RMS | Dual Voice Coil 2 Ohm or 4 Ohm
XD 10″ Car Subwoofer | 450 Watts RMS | Dual Voice Coil 2 Ohm or 4 Ohm
2 Ohms / Version 2
American Bass Audio Warehouse
1605 Enterprise Parkway
Twinsburg OH 44087
United States
| PRODUCT INFO | ||
| MPN | XD-1022 | |
| UPC | 636823698478 | |
Ready to add some thunder to your ride? The XD Series subwoofer from American Bass is here to help! With its high-grade design and tight bass response, this subwoofer delivers plenty of clarity and depth to your car's audio system. Plus, with its even power output and fan-favorite status as one of our best-selling subwoofers, you can count on the XD Series to provide an all-around excellent audio experience that's sure to please most car audio enthusiasts. So why wait? Upgrade your car's audio system today with the powerful and versatile XD Series subwoofer!
| GENERAL SPECIFICATIONS | ||
| Size (Inch) | 10.0 | |
| Voice Coil Size (Inch) | 2.4 | |
| Voice Coil Wire | Hi-temp 4-layer voice coil |
|
| Surround Material | Foam |
|
| Cone | Kevlar reinforced paper |
|
| Cone Material | Paper |
|
| Frame Material | Stamped steel |
|
| Magnet Type | Ferrite |
|
| RMS Power (Watts) | 500 | |
| Max Power (Watts) | 1000 | |
| Sensitivity (dB) | 84.4 | |
| T/S PARAMETERS | ||
| SPL (dB) | 84.4 | |
| Xmax (mm) | 11.35 | |
| Qes | 0.582 | |
| Qms | 6.655 | |
| BL | 17.27 | |
| Mms (g) | 175.896 | |
| Fs (Hz) | 43.625 | |
| Qts | 0.535 | |
| Impedance (Ohm) | 2 | |
| Subwoofer Measurements | ||
| Mounting Depth | 6.1 | |
| Mounting Diameter | 10.08 | |
| PRODUCT INFO | ||
| MPN | XD-1022v2 | |
| UPC | ||
Ready to add some thunder to your ride? The XD Series subwoofer from American Bass is here to help! With its high-grade design and tight bass response, this subwoofer delivers plenty of clarity and depth to your car's audio system. Plus, with its even power output and fan-favorite status as one of our best-selling subwoofers, you can count on the XD Series to provide an all-around excellent audio experience that's sure to please most car audio enthusiasts. So why wait? Upgrade your car's audio system today with the powerful and versatile XD Series subwoofer!
| GENERAL SPECIFICATIONS | ||
| RMS Power (W) | 450 | |
| MAX Power (W) | 900 | |
| Size (Inch) | 10.0 | |
| Voice Coil Size (Inch) | 2.5 | |
| Voice Coil Wire | Copper |
|
| Surround Material | Stitched Foam |
|
| Cone | Fiberglass |
|
| Cone Material | Paper |
|
| Frame Material | Heavy Duty |
|
| Magnet Type | Ferrite |
|
| Magnet Weight | 130 Oz |
|
| RMS Power (Watts) | 450 | |
| Max Power (Watts) | 900 | |
| Frequency Response | 30-500 Hz | |
| T/S PARAMETERS | ||
| SPL (dB) | 83.2 | |
| Re (Ohm) | 1.9 | |
| Xmax (mm) | 13.0 | |
| Qes | 0.73 | |
| Qms | 6.05 | |
| BL | 13.8 | |
| Mms (g) | 185.0 | |
| Fs (Hz) | 34.9 | |
| Vas (L) | 18.8 | |
| Sd (sq.m) | 330 | |
| Qts | 0.65 | |
| Le (mH) | 2.1 | |
| Impedance (Ohm) | 2 | |
| Subwoofer Measurements | ||
| Mounting Depth | 6.2 | |
| Mounting Diameter | 9.24 | |
| PRODUCT INFO | ||
| MPN | XD-1044 | |
| UPC | 636823698232 | |
Ready to add some thunder to your ride? The XD Series subwoofer from American Bass is here to help! With its high-grade design and tight bass response, this subwoofer delivers plenty of clarity and depth to your car's audio system. Plus, with its even power output and fan-favorite status as one of our best-selling subwoofers, you can count on the XD Series to provide an all-around excellent audio experience that's sure to please most car audio enthusiasts. So why wait? Upgrade your car's audio system today with the powerful and versatile XD Series subwoofer!
| GENERAL SPECIFICATIONS | ||
| Size (Inch) | 10.0 | |
| Voice Coil Size (Inch) | 2.4 | |
| Voice Coil Wire | Hi-temp 4-layer voice coil |
|
| Surround Material | Foam |
|
| Cone | Kevlar reinforced paper |
|
| Cone Material | Paper |
|
| Frame Material | Stamped steel |
|
| Magnet Type | Ferrite |
|
| RMS Power (Watts) | 500 | |
| Max Power (Watts) | 1000 | |
| Sensitivity (dB) | 83.1 | |
| T/S PARAMETERS | ||
| SPL (dB) | 83.1 | |
| Xmax (mm) | 11.35 | |
| Qes | 0.72 | |
| Qms | 4.211 | |
| BL | 20.82 | |
| Mms (g) | 186.41 | |
| Fs (Hz) | 41.727 | |
| Vas (L) | 13.295 | |
| Qts | 0.616 | |
| Impedance (Ohm) | 4 | |
| Subwoofer Measurements | ||
| Mounting Depth | 6.1 | |
| Mounting Diameter | 10.08 | |
| PRODUCT INFO | ||
| MPN | XD-1044v2 | |
| UPC | ||
Ready to add some thunder to your ride? The XD Series subwoofer from American Bass is here to help! With its high-grade design and tight bass response, this subwoofer delivers plenty of clarity and depth to your car's audio system. Plus, with its even power output and fan-favorite status as one of our best-selling subwoofers, you can count on the XD Series to provide an all-around excellent audio experience that's sure to please most car audio enthusiasts. So why wait? Upgrade your car's audio system today with the powerful and versatile XD Series subwoofer!
| GENERAL SPECIFICATIONS | ||
| RMS Power (W) | 450 | |
| MAX Power (W) | 900 | |
| Frequency Range | 30-500 Hz | |
| Size (Inch) | 10.0 | |
| Voice Coil Size (Inch) | 2.5 | |
| Voice Coil Wire | Copper |
|
| Surround Material | Stitched Foam |
|
| Cone | Fiberglass |
|
| Cone Material | Paper |
|
| Frame Material | Heavy Duty |
|
| Magnet Type | Ferrite |
|
| Magnet Weight | 130 Oz |
|
| RMS Power (Watts) | 450 | |
| Max Power (Watts) | 900 | |
| T/S PARAMETERS | ||
| SPL (dB) | 83.4 | |
| Re (Ohm) | 3.2 | |
| Xmax (mm) | 13.0 | |
| Qes | 0.77 | |
| Qms | 5.54 | |
| BL | 18.0 | |
| Mms (g) | 168.0 | |
| Fs (Hz) | 36.8 | |
| Vas (L) | 16.9 | |
| Sd (sq.m) | 330 | |
| Qts | 0.68 | |
| Le (mH) | 2.93 | |
| Impedance (Ohm) | 4 | |
| Subwoofer Measurements | ||
| Mounting Depth | 6.2 | |
| Mounting Diameter | 9.24 | |
-
